Professional Ironers

Roller Ironers
Flatwork Ironers

Specifications

Model: RI-160-40 | RI-160-60 | RI-200-40 | RI-200-60 | RI-300-40 | RI-300-60

General specifications of the roller

Useful roller length (mm):
1,500 | 1,500 | 2,000 | 2,000 | 3,000 | 3,000
Roller diameter Ø (mm):
400 | 600 | 400 | 600 | 400 | 600
Operating speed (m/min):*
12–45 | 12–45 | 8–30 | 12–45 | 8–30 | 12–45
Wet air outlet diameter Ø (mm):
80 | 80 | 80 | 97 | 97 | 122
Humid air flowrate (m³/h):
115 | 150 | 150 | 280 | 280 | 390

Device dimensions

Width/L (mm):
2300 | 2300 | 2650 | 2650 | 3500 | 3500
Depth/P (mm):
630 | 680 | 630 | 680 | 650 | 680
Height/H (mm):
1070 | 1100 | 1070 | 1100 | 1070 | 1100

Weight

Net weight (kg):
450 | 530 | 620 | 710 | 910 | 1060
Gross weight (kg):
480 | 550 | 680 | 750 | 960 | 1100

Packaging dimensions

Width/L (mm):
2600 | 2600 | 3150 | 3150 | 4200 | 4200
Depth/P (mm):
900 | 900 | 1050 | 1050 | 1270 | 1270
Height/H (mm):
1370 | 1400 | 1370 | 1400 | 1400 | 1400

Steam inlet specifications

Steam Connection (NPT):
1/2″ | 1/2″ | 3/4″ | 3/4″ | 1″ | 1″
Steam Pressure (bar):
4–7 | 4–7 | 4–7 | 4–7 | 4–7 | 4–7

Voltage

Electrical Heating source:
380–415V
3ph–50/60Hz
220–240V
Gas & Steam Heating source:
380–415V
3ph–50/60Hz

Control

Just one temperature and speed control:
• Electric — • Gas — • Steam
Several temperature and speed controls:
• Electric — • Gas — • Steam

Heating source

Electrical / Steam / Gas Steam
(• Optional / * Standard / – Not available)

Professional Ironers

Roller Ironers
Flatwork Ironers

These models come in different sizes and capacities, designed for industrial and commercial use:

Size (cm)	Model Type	Capacity (kg)
160	Roller Ironers	40/60
200	Roller Ironers	40/60
300	Roller Ironers	40/60
200	Flatwork Ironers	60/80
300	Flatwork Ironers	60/80

These models are engineered to effectively and efficiently meet the diverse ironing needs of industrial and commercial applications.
